Pipe Inspection Camera system with DVR (TEC-Z710DM) Details

Best quality high resolution cheap pipe camera TEC-Z710DM





Product Description



Specification

camera

1. camera size: 23mmx120mm front size:45mm

2.Camera case material: stainless steel house stainless steel 304

3. Camera glass material: sapphir glass

4. sensor size: 1/4 inch

5.Total Pixels: PAL: 720X576 NTSC: 720X480

6. view angle: 120°

7. camera light: 12PCS white LEDS

8. Special gold point touch connector

9. waterproof: IP68

10.camerawork current: 100MA camara power supply: DC 12V

11. LEDS ADJUASTABLE

12.Work temperature: -10°C-50°C



monitor

1. monitor size: 7inch TFT color monitor

2. monitor Total Pixels: 1440X234

3. monitor power supply: DC 12V

4. osd language: english

5. up, down left, right adjustable

6. 16:9 4: 3 model

7. sunshade includ

8. waterproof connector

9. Work temperature: -10°C-50°C



DVR

1. DVR power supply: 12V

2. DVR work current: 200MA

3. storage medium: SD card (max 32G)

4. dagital clock and dagital calendar

5. DVR Total Pixels: 720X576 (D1)

6. picture snap and movie record

7. movie format: AVI

8. audio record (yes)

9. double earphone output



Audio input unit

1. micphone

2. clip type



Cable wheel

Cable size: 320MM(diameter)X110(h)

Wire material: fiberglass rod

Fiberglass length: 20M( standard)

Fiberglass diameter: 4.8MM

Fiberglass color: yellow



battery

Battey pype: 12V 4000MAH rechargable li –ion battery(18650)

Tatal work time : more 7 hours



charger

input: AC90-260V output: DC 12V 1000MA

Output cable length: 1.5M

DC plug diameter : 2.1MM



box

box material: fire protection

Box size: 48cm x 39cm x 19.5cm



SKIDS size

1. SKIDS1: material POM Φ40MM

2. SKIDS2: material POM Φ80MM



Weight and cartoon size

net weight: 7.5KG Single

gross weight: 8.5KG Single

Single package size

Double package size

 23mm camera

 23mm camera

DVR


cable

 cable & 23mm camera head with light.jpg

7 inch LCD screen

monitor





Packaging & Shipping

Aluminum box

Sell Top One Video Pipe Inspection Camera with Memory Card,Sewer Drain Camera Surveillance Camera System TEC-Z710DM


 ABS box

ABS box
