Economical but professional door frame metal detector TEC-201 (CP-81023483514) Details

Economical but professional door frame metal detector TEC-201

 1.jpg2.jpg【Performance and Features】

  • Accurate positioning: 6 overlapping network detecting area, bilateral transceivers,accurately locate the detected metals,visually display the target object.
  • Microprocessor Technology :By microcomputer control circuit generates electromagnetic scanning.The scan rate can be precisely controlled.

 Set via control panel according to your need,to ensure sensitivity setting with flexibility,reliability,and stability.

  • Sound and light alarm:adjustable volume,three choices:muted,bass,and treble;suitable for used in different occasions.
  • Adjustable sensitivity:Each detection zone has 100 sensitivity levels(0~99),preset sizes of detected metals,to rule out coins,keys,jewelry,belt buckle,etc false alarm.
  • Digital pulse technology:equipped with digital signal processing filter system, with excellent anti-interference capability.
  • Password protection settings:Only enter into correct password,can you set the sensitivity level and other parameters.Four-digit password,the user can set own.
  • Remote control:can set the parameters by remote control.
  • Counting statistics:counting passing through people and alarm times.
  • Harmless:Harmless to human body pacemaker,pregnant,magnetic floppy disks,magnetic tape,etc.
  • Power safety:placed on the top of device,higher waterproof.
  • Waterproof fixing foot sleeve :not only fix the door,but also waterproof。
  • Waterproof:Adopt PVC composite material with special manufacturing processing, higher waterproof,fireproof,shockproof.
  • Easy installation:integrated design,can be installed and disassembled within 20 minutes.

【Technical parameters】


  • Net weight:67KG
  • Power:<20W
  • Working temperature:-20℃~45℃
  • Channel size:2000mm(H)×700mm(W)×605mm(D)
  • Dimension:2230mm(H)×830mm(W)×730mm(D)
  • Package size(door panel): 2300mm(L)×740mm(W)×260mm(H)
  • Package size(main chasis):780mm(L)×480mm(D)×270mm(H)

Factory parameters】

  • password1234
  • Alarm duration1 second
  • Alarm volumetreble
  • 1~6 detection zone sensitivity90
  • Language: Chinese&English

Control Unit of metal detector gate


LED panel


Package
